4.0inch color TFT panel 480*800 5 points touch mode display high contrast wide viewing angle factory wholesale TFT screen

Part No.:ET040WV01-OT
Size:4″ inch
Resolution:480x800
Panel Interface:
Display mode:Transmissive
Outline Dimension:58.26x98.1x3.63mm
Active Area:51.84(H)x86.4(V)mm
Viewing Angle L/R/U/D:80 80 80 80
Brightness（cd/m2）:400cd/m2
Operation / Storage Temp:-20~70℃ / -30~80℃
Touch:yes

4.0inch color TFT panel 480*800 5 points touch mode display high contrast wide viewing angle factory

wholesale TFT screen

Model No.:	ET040WV01-OT	Brightness:	400
Brand:	Youritech	Interface:	MCU
Panel Size:	4.0"	Viewing Angle:	80 80 80 80
Pixel:	480(RGB)*800	Display Mode:	Transmissive/Normally Black
Active Area:	51.84(H)*86.4(V)mm	Storage Temperature:	-30~80℃
Contrast Ratio:	800:1	Operation Temperature:	-20~70℃
