LB238WFM-SSA1 Original 23.8 Inch 1920x1080 Resolution with Free Angle LVDS 30 Pins LCD Display For Medical Imaging

  • Part No.:LB238WFM-SSA1
  • Size:23.8″ inch
  • Resolution:1920x1080
  • Panel Interface:LVDS (2 ch,8-bit)
  • Display mode:IPS,Transmissive
  • Outline Dimension:535x313x12.4(HxVxD)
  • Active Area:527.04x296.46(HxV)
  • Viewing Angle L/R/U/D:89/89/89/89 (Typ.)
  • Brightness(cd/m2):350cd/m²
  • Operation / Storage Temp:0~50°C / -20~60°C
  • Touch:no

Products Description

LB238WFM-SSA1-TFT-23.8inch-1920x1080-LVDS-3

LCD SPECIFICATION
Panel Size 23.8" Panel Type LCM , a-Si TFT-LCD
Pixel Number 1920(RGB)×1080 (FHD) 92PPI Configuration RGB Vertical Stripe
Active Area(mm) 527.04 × 296.46 (H×V) Outline(mm) 535 × 313 × 12.4 (H×V×D)
Bezel Area(mm) - Treatment Antiglare (Haze 44%), Hard coating (3H)
Luminance 350 cd/m² (Typ.) Contrast Ratio 1000 : 1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Display Mode IPS, Normally Black, Transmissive
View Direction Symmetry Response Time 14 (Typ.)(G to G) ms
Support Color 16.7M 72% NTSC Backlight 15S4P WLED , 30K hours , No Driver
Panel Weight 1.91/2.01Kgs (Typ./Max.) Used for Industrial, Medical Imaging
Frequency 60Hz Touchscreen Without
Signal Interface LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage 5.0V (Typ.)
Environment Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

LB238WFM-SSA1_01LB238WFM-SSA1_02LB238WFM-SSA1_03
