(23.8")

2K 23.8 inch LCD Display 1920x1080 Resolution LVDS 30 Pins Interface Screen High Brightness LCD Panel

Part No.:G238HCJ-L02
Size:23.8″ inch
Resolution:1920x1080
Panel Interface:LVDS (2 ch,8-bit)
Display mode:AAS,Transmissive
Outline Dimension:540.24x315.66mm
Active Area:527.04x296.46mm
Viewing Angle L/R/U/D:89/89/89/89 (Typ.)
Brightness（cd/m2）:450cd/m²(Typ.)
Operation / Storage Temp:0~60°C / -20~60°C
Touch:no

Products Description

G238HCJ-L02-TFT-23.8inch-1920x1080-LVDS-3

LCD SPECIFICATION
Panel Size	23.8"	Panel Type	a-Si TFT-LCD, LCM
Pixel Number	1920(RGB)×1080, FHD	Configuration	RGB Vertical Stripe
Active Area(mm)	527.04×296.46 mm	Outline(mm)	540.24×315.66 mm
Bezel Area(mm)	530.2×299.6 mm	Treatment	Antiglare (Haze 25%), Hard coating (3H)
Luminance	450 cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
Viewing Angle	89/89/89/89 (Typ.)	Display Mode	AAS, Normally Black, Transmissive
Signal Interface	LVDS (2 ch, 8-bit)
Environment	Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C

G238HCJ-L02_02 G238HCJ-L02_03
