7.1"-10.1" LCD Display (9.2")

9.2 Inch TFT LCD Display 462×1920 MIPI LCD Display For Automotive

Part No.:ET092BA01-TH
Size:9.2″ inch
Resolution:462x1920
Panel Interface:MIPI
Display mode:Transmissive
Outline Dimension:66x249.4mm
Active Area:54.442x226.253mm
Viewing Angle L/R/U/D:85/85/85/85
Brightness（cd/m2）:400nits
Operation / Storage Temp:-20~60°C / -20~60°C
Touch:no

9.2 Inch TFT LCD Display 462×1920 MIPI LCD Display For Automotive Video

9.2 Inch TFT LCD Display 462×1920 MIPI LCD Display For Automotive Overview

ET092BA01-TH is a 9.2-inch diagonal TFT-LCD display product with a transmissive display mode. ET092BA01-TH supports a resolution of 462×1920 with an aspect ratio of 1:4 (W:H), delivering a long vertical display format, and utilizes a MIPI interface for signal transmission. It features an active area of 54.442(W)×226.253(H) mm and an outline size of 66(W)×249.4(H) mm. The display provides a brightness of 400 cd/m², suitable for automotive applications, and offers wide viewing angles of 85/85/85/85 (L/R/U/D). ET092BA01-TH operates within a temperature range of -20 to 60°C and can be stored at -20 to 60°C. This model does not include a touch function.
