3.7 Inch Stretched Bar Display 240x960 IPS 3SPI+16bit RGB Interface TFT LCD Display

3.7 Inch Stretched Bar Display Overview
ET037VG07-T is a 3.7-inch diagonal stretched bar TFT-LCD display module operating in transmissive mode. It supports a resolution of 240×960 pixels and adopts IPS technology for wide viewing angles (L/R/U/D). Featuring a 3SPI + 16-bit RGB interface, the module ensures stable signal transmission and easy integration. It offers an active area of 22.86(W) × 91.44(H) mm within an outline dimension of 25.3(W) × 98.89(H) mm, delivers a typical brightness of 350 cd/m², supports an operating temperature range of –20°C to 70°C and storage temperature of –30°C to 80°C, and does not include a touch panel.

More 3.7 Inch Bar Displays For Reference
ET037VG06-T (240×960, MIPI, IPS, 350nits, -20~70°C, 28.989×92.692mm)
ET037BA01-Z (240×960, TTL, IPS, 350nits, -20~70°C, 25.3×98.89mm)
ET037VG07-T(240×960, IPS, 350nits, 3SPI+16bit RGB, 25.3x98.89mm)
