3.6 Inch TFT LCD Display 1024×768 MIPI 900nits High Brightness LCD Display With On-Cell Touch For Cycling Computer Bike Display

Part No.:QV036X0M-T40
Size:3.6″ inch
Resolution:1024x768
Panel Interface:MIPI (4 data lanes)
Display mode:Transmissive
Outline Dimension:79.8x63.7mm
Active Area:72.96x54.72mm
Viewing Angle L/R/U/D:85/85/85/85
Brightness（cd/m2）:900cd/m²
Operation / Storage Temp:-20~70°C / -30~80°C
Touch:yes

3.6 Inch Cycling Computer Bike Display Overview
QV036X0M-T40 is a 3.6-inch diagonal TFT-LCD display module featuring a transmissive display mode. It supports a resolution of 1024×768 with a 4:3 aspect ratio (W:H) and adopts a MIPI (4 data lanes) interface for high-speed transmission. The display offers an active area of 72.96 (W) × 54.72 (H) mm and an outline dimension of 79.8 (W) × 63.7 (H) mm. With a brightness of 900 cd/m², it ensures good visibility in various lighting conditions, making it suitable for cycling computer and bike display applications. It provides wide viewing angles of 85/85/85/85 (L/R/U/D) and operates within a temperature range of -20°C to 70°C (storage: -30°C to 80°C). This module integrates on-cell touch functionality.
