21.5 Inch 4K 3840x2160 LCD Display 1400nits High Brightness eDP IPS LCD Module

21.5 Inch 4k Display Overview
P2150UHF1MA00 supports display 3840(RGB)×2160 (UHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. It features active area of 475.2(W)×267.3(H) mm, outline size of 495.2(W)×291.9(H) mm. As a SFT, Normally Black, Transmissive LCM product, P2150UHF1MA00 can provides 1400 cd/m² display brightness 1200:1 transimissive contrast ratio, 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry . Gray scale or the brightness of the sub-pixel is determined with a 8-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 1.07B colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. P2150UHF1MA00 utilizes eDP as it's signal inputting systerm. It's typical vertical frame rate (Fv) is 60Hz.
