17.4 Inch TFT LCD Display 1200×1920 LVDS High Brightness 800nits Wide Temperature LCD Display For Automotive

17.4 Inch Automotive Display Overview
COG-VLBJT035-01 supports display 1200×1920(RGB) (WUXGA) with aspect ratio of 10:16 (W:H), whose pixels are arranged in RGB Horizontal Stripe. As for mechanical detail, it features active area of 234(W)×374.4(H) mm, outline size of 250.8(W)×386.8(H)×19.1(D) mm. As a ADS, Normally Black, Transmissive LCM product, COG-VLBJT035-01 can provides 800 cd/m² display brightness 1000:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 40 (Max.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 71% (NTSC). This product adopted 12S6P WLED as it's backlight systerm which was placed as Edge light type, With LED Driver. COG-VLBJT035-01 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.). It's typical vertical frame rate (Fv) is 75Hz.
