Factory Supply 10.5 Inch 60Hz 1200x1920 Resolution with MIPI 34 Pins Connector Free Angle LCD Display Screen

  • Part No.:TV105WUM-AS0
  • Size:10.5″ inch
  • Resolution:1200x1920
  • Panel Interface:MIPI (4 data lanes)
  • Display mode:/
  • Outline Dimension:156.18(H)x255.06(V)x4.44(D)mm
  • Active Area:141.3(H)x226.08(V)mm
  • Viewing Angle L/R/U/D:85/85/85/85
  • Brightness(cd/m2):480cd/m²
  • Operation / Storage Temp:-20~85°C / -55~125°C
  • Touch:no

Products Description

TV105WUM-AS0

Product size 10.5-inch Type a-Si TFT-LCD , Assembly
Pixel Format 1200(RGB)×1920 [WUXGA] 215PPI Configuration RGB Vertical Stripe
Active Area 141.3(H)×226.08(V) mm Outline Dim. 156.18(H)×255.06(V) ×4.44(D) mm
Bezel Area - Treatment Hard coating
Luminance 480 cd/m² (Typ.) Contrast Ratio 900:1 (Typ.) (TM)
View Direction Symmetry Response Time 25 (Typ.)(Tr+Td)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Operating Mode -
Support Color 16.7M 92% DCI-P3 Light Source WLED [4 strings] , W/O Driver
Weight 216g (Typ.) Designed For Pad & Tablet
Frequency 60Hz Touch Panel PCAP
Interface Type MIPI (4 data lanes) , 34 pins Connector
Power Supply 1.8/5.8/-5.8V (Typ.)(VDD/VSP/VSN)
Environment Operating Temperature: -20 ~ 85 °C ; Storage Temperature: -55 ~ 125 °C

TV105WUM-AS0_01TV105WUM-AS0_02TV105WUM-AS0_03TV105WUM-AS0_04TV105WUM-AS0_05
