DV236FBM-N00 BOE 23.6 Inch Circular Display 1280x1280 Sunlight Readable Round LCD For Digital Signage

Part No.:DV236FBM-N00
Size:23.6″ inch
Resolution:1280x1280
Panel Interface:LVDS (2 ch,8-bit)
Display mode:Transmissive
Outline Dimension:657(H)x657(V)mm
Active Area:599.424(H)x599.424(V)mm
Viewing Angle L/R/U/D:89/89/89/89 (Typ.)
Brightness（cd/m2）:1500(Typ.)
Operation / Storage Temp:0~50°C / -20~60°C
Touch:no

Overview
DV236FBM-N00 is a 23.6 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, With LED Driver, without touch screen.DV236FBM-N00 supports display 1280(RGB)×1280 with aspect ratio of 1:1 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 599.424(W)×599.424(H) mm, outline size of 657(W)×657(H)×29.15(D) mm, viewing area size of 603.42(W)×603.42(H) mm, with surface treament of Antiglare (Haze 25%), net weight of TBD. As a ADS, Normally Black, Transmissive LCM product, DV236FBM-N00 can provides 1500 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 14 (Typ.)(G to G) ms.

Feature
-All O'clock
-Sunlight Readable
-WLED Backlight

Screen Size:23.6 inch
Resolution:1280x1280
Brand:BOE
23.6 Inch Circular Display 1280x1280 Sunlight Readable Round LCD.

Application
For Digital Signage.
