26.5 Inch 4K AMOLED Display 3840x2160 V-by-One 32 lane IPS LCD Display

26.5 Inch 4k Display Overview
QMC265AA01-D02 supports display 3840(RGB)×2160 (UHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in Q-Square.It features active area of 589.97(W)×332.93(H) mm, outline size of 606.31(W)×344.2(H) mm, with surface treament of Hard coating (2H), Antireflection, net weight of 850g (Max.). As a Normally Black OLED product, QMC265AA01-D02 can provides 250 cd/m² display brightness 1500000:1 transimissive contrast ratio, 89/89/89/89 (Min.)(CR≥10000) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 0.1 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 1.07B colors, also with performance of color gamut 99% (DCI-P3). This product emiting itself and have a working life time of 30K hours. QMC265AA01-D02 utilizes V-by-One 32 lane as it's signal inputting systerm, which connected by 163 pins Connector with power supply voltage of 10.5/19V (Typ.)(VDD/ELVDD). It's typical vertical frame rate (Fv) is 240Hz.

4k &8K Display Applications

Production and Manufacturing
