19 Inch 1280x1024 Square Display Products Description
19 Inch 1280x1024 Square Display Overview
ET190SQ01-K-HDMI is a 19-inch diagonal TFT LCD display module designed for industrial and commercial applications. It supports a 1280×1024 resolution with a square aspect ratio, whose pixels deliver clear and stable image performance. The display adopts an HDMI interface for convenient and high-quality signal transmission, and features a Normally Black display mode. It has an active area of 376.32(W) × 301.06(H) mm and an outline size of 423(W) × 347.7(H) × 37(D) mm. ET190SQ01-K-HDMI can provide a high brightness of 720 cd/m², ensuring good visibility in various lighting environments, and it supports an operating temperature range of -20°C to 70°C and storage temperature of -30°C to 80°C. This model does not include a touch panel.
19 Inch 1280x1024 Square Display Application
For industrial & smart home appliances & medical instruments & automotive display.
More Square Displays For Reference
| Inch | Resolution | LCM Driver chip | LCM Dimensions | Display area | Interface | Reference brightness |
| 0.85 | 128*128 | ST7735S / GC9107 | 17.58*20.82*1.5 | 15.2064*15.2064 | SPI | 260 |
| 1.3 | 240*240 | ST7789V | 26.2*29.22*1.5 | 23.4*23.4 | MCU 8 BIT | 450 |
| 240*240 | ST7789V | 26.2*29.22*1.5 | 23.4*23.4 | MCU 8 BIT | 1000 | |
| 240*240 | ST7789V | 26.2*29.22*1.5 | 23.4*23.4 | MCU 8 BIT | 400 | |
| 240*240 | ST7789V | 26.2*29.22*1.5 | 23.4*23.4 | SPI4 | 450 | |
| 1.44 | 128*128 | ST7735S | 32.36*38*2.6 | 26.5*26.5 | SPI4 | 300 |
| 1.5 | 128*128 | SSD1351 | 33.80*34.00*1.60 | 26.855*26.864 | 8-bit parallel, 3-/4-wire SPI | 90 |
| 1.54 | 320*320 | ST7796 | 31.52*33.72*1.65 | 27.22*27.72 | MIPI | 700 |
| 320*320 | ST7796 | 31.52*33.72*1.65 | 27.22*27.72 | RGB 16 BIT | 700 | |
| 240*240 | ST7789 | 31.92*35.11*2.13 | 27.22*27.72 | MCU 8 BIT | 900 | |
| 240*240 | ST7789V | 31.52*33.72*1.81 | 27.22*27.72 | SPI4 | 750 | |
| 240*240 | ST7789V | 31.52*34.71*2.03 | 27.22*27.72 | MCU 8 BIT | 800 | |
| 240*240 | ST7789V | 31.92*35.11*1.81 | 27.22*27.72 | RGB 6 BIT | 450 | |
| 1.54 | 152*152 | SSD1681 | 31.8* 37.3* 1.14 | 27.512* 27.512 | SPI | 0 |
| 1.54 | 200x200 | SSD1681 | 31.8 x 37.32 x 0.98 | 27.00 x 27.00 | SPI | 0 |
| 3.4 | 480x480 | ST7701SN-G5 | More choose | More choose | MIPI | 550 |
| 3.92 | 320*320 | ST7355P | 74.86*76.73*2.13 | 71.14*69.82 | SPI/MCU | 350 |
| 3.95 | 480*480 | ST7701S | 81.8*84.95 | 71.93*71.93 | RGB 18 BIT | 350 |
| 480*480 | ST7701S | 83*83*3.06 | 71.93*71.93 | MIPI 2 LANE | 350 | |
| 4 | 720*720 | More choose | 77*80*14 | 71.928*71.928 | Type C | 700 |
| 4.2 | 720*672 | More choose | More choose | More choose | RGB/SPI | More choose |
| 7 | 720*720 | More choose | More choose | More choose | LVDS | More choose |
| 17 | 1920*1920 | More choose | 325.01*319.33*12.2 | 305.28*305.28 | eDP | 600 |
| 19 | 1280*1024 | H-DMI | 423*347.7*37 | 376.32*301.06 | HDMI | 720 |
| 22 | 1920*1920 | More choose | 394.56*394.56 | 409.56*409.56*12.6 | LVDS | 500 |
| 28.1 | 800*800 | More choose | 504*504 | 526.8*526.8*28 | LVDS | 700 |
| 33 | 1920*1920 | More choose | 596.16*596.16 | 612.96*612.96 | LVDS | 420 |
| 44.9 | 1280*1280 | More choose | 806.4*806.4 | 829.2*829.2*27.1 | LVDS | 700 |
| Touch Screens are Available and Optional | ||||||
19 Inch 1280x1024 Square Display Custom LCD Solutions for Diverse Applications
Brightness from 0-3000 for perfect display effect achievement.
100% NTSC makes the vividness of the picture better and the color transition in the picture more natural.
Color Temperature is positive white at around 5500K, warm white (yellowish) at 3500K and also cool white (cold) at 6500K.
Driver circuit with sufficient voltage and current values to meet output requirements and reduce the secondary development cycle.
Heat dissipation for high-brightness products to advance design of reasonable heat dissipation structure
Power consumption, we increase the brightness without increasing the power consumption.
Cables, Backlighting also requires cables, either through an FPC connected to the LCD's FPC and controlled through a port, or a separate cable that controls it through a connector.
LED life reached the standard of 30K hours Min. 50K, 70K, 100K hours are all achievable.
19 Inch 1280x1024 Square Display Touch screen,standard type and customization
19 Inch 1280x1024 Square Display Driver board/adapter board, standard type and design customization
DEMO board, H-DMl board, other customized board, etc.
19 Inch 1280x1024 Square Display Embedded Integrated Solution
UART display solution, H-DMl display solution, Window display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
At Youritech, we design and manufacture standard, semi-custom and full custom LCD/OLED display modules,touch screen,driver board,open frame. Contact us today,let our engineering team quickly and accurately feedback you with details.
