VS025ZSM-NV0-69P0 2.5 Inch 1440x1600 TFT LCD Screen IPS LCD Display With MIPI Interface For HMD VR AR

  • Part No.:VS025ZSM-NV0-69P0
  • Size:2.5″ inch
  • Resolution:1440x1600
  • Panel Interface:MIPI (2 ch,4 data lanes)
  • Display mode:Transmissive
  • Outline Dimension:46.6(H)x55.5(V)mm
  • Active Area:43.2(H)x48(V)mm
  • Viewing Angle L/R/U/D:80/80/80/80 (Typ.)
  • Brightness(cd/m2):150(Typ.)
  • Operation / Storage Temp:0~50°C / -20~60°C
  • Touch:no

VS025ZSM-NV0-69P0 Overview
VS025ZSM-NV0-69P0 is a 2.5 inch diagonal a-Si TFT-LCD display panel, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized in the following: WLED Backlight . Based on its features, we recommend that this model be applied to HMD VR AR etc.

Screen Size:2.5 inch
Resolution:1440x1600
Brand: BOE
Luminance:150 cd/m² (Typ.)
Refresh Rate:90Hz
Signal Type:MIPI (2 ch, 4 data lanes) , 24 pins Connector

VS025ZSM-NV0-69P0 Feature
-IPS Full Viewing Angle
-High contrast
-Wide temperature range
-Low power consumption



VS025ZSM-NV0-69P0 Application
Head-mounted Displays, Viewfinders, Small Display,AR VR etc.

As one of the Pioneers within microdisplays products, Youritech have pushed energy efficiency to the edge, delivering high-performance Near-Eye Displays (NED) for a wide range of products, that include video glasses, head-mounted sports devices, camera viewfinders, medical applications, and many other professional devices worldwide.
