VS019U0M-NH0-DKP0 BOE 1.9 Inch 1600x1200 LCD MIPI Interface LCD Display With HDMI to MIPI board For HMD AR VR

  • Part No.:VS019U0M-NH0-DKP0
  • Size:1.9″ inch
  • Resolution:1600x1200
  • Panel Interface:MIPI (2 ch,4 data lanes)
  • Display mode:Transmissive
  • Outline Dimension:41.2(W)x40.6(H)mm
  • Active Area:38.4(W)x28.8(H)mm
  • Viewing Angle L/R/U/D:25/25/35/35 (Typ.)
  • Brightness(cd/m2):1000cd/m²(Typ.)
  • Operation / Storage Temp:-10~55°C / -30~70°C
  • Touch:no

VS019U0M-NH0-DKP0 Overview
VS019U0M-NH0-DKP0 is a 1.9" diagonal LTPS TFT-LCD display panel, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -10 ~ 55°C , a storage temperature range of -30 ~ 70°C . It's general features are summarized in the following: 120Hz, Ultra High Brightness, WLED Backlight.Based on its features, we recommend that this model be applied to HMD VR AR etc.

Screen Size:1.9 inch
Brand: BOE
1.9 Inch 1600x1200 Ultra High Brightness LCD With HDMI to MIPI Board

VS019U0M-NH0-DKP0 Feature
-IPS Full Viewing Angle
-High contrast
-LCD With HDMI to MIPI Board
-Ultra High Brightness
-Wide temperature range
-Low power consumption

VS019U0M-NH0-DKP0 Application
Head-mounted Displays, Viewfinders, Small Display,AR VR etc.

As one of the Pioneers within microdisplays products, Youritech have pushed energy efficiency to the edge, delivering high-performance Near-Eye Displays (NED) for a wide range of products, that include video glasses, head-mounted sports devices, camera viewfinders, medical applications, and many other professional devices worldwide.


At Youritech, we design and manufacture standard, semi-custom and full custom LCD/OLED display modules,touch screen,driver board,open frame. Contact us today,let our engineering team quickly and accurately feedback you with details.
