SY103WAM19 1.03 Inch 2560x2560 Si-OLED Panel Sunlight Readable MIPI Interface AMOLED For HMD AR VR

Part No.:SY103WAM19
Size:1.03″ inch
Resolution:2560x2560
Panel Interface:MIPI(1 or 2-port D-PHY)
Display mode:Si-OLED,OLED
Outline Dimension:/
Active Area:18.432mmx18.432mm
Viewing Angle L/R/U/D:/
Brightness（cd/m2）:1000nits
Operation / Storage Temp:-20~70°C / -30~80°C
Touch:no

SY103WAM19 Overview
SY103WAM19 is a 1.03inch diagonal, 2560(RGB) x 2560 dots active-matrix color OLED module, based on single-crystal siliconbackplate. This module integrates display driver and pixel driver circuit, and realizes small size, light weight, low powelconsumption and high resolution.
Screen Size:1.03 inch
Resolution:2560x2560
Brand:SeeYA
High Resolution OLED Panel
Refresh Rate:90Hz

Feature
-High contrast
-Wide color gamut
-Quick response
-Sunlight Readable
-Brightness:1000nits
-Operating Temp. :-20 ~ 70 °C
-Storage Temp. :-30 ~ 80 °C

Application
Head-mounted Displays, Viewfinders, Small Display,AR VR etc.
