Original new 18.4 inch 4k LCD panel 3840x2160 IPS LCD Display EDP interface for laptop

Part No.:NV184QUM-N21
Size:18.4″ inch
Resolution:3840x2160
Panel Interface:eDP (4 Lanes),eDP1.3
Display mode:ADS,Transmissive
Outline Dimension:443.4(H)x266.5(V)
Active Area:408.96(H)x230.04(V)
Viewing Angle L/R/U/D:85/85/85/85 (Typ.)
Brightness（cd/m2）:260(Typ.)
Operation / Storage Temp:0~50°C / -20~60°C
Touch:no

Product Description

Product size	18.4-inch	Type	LCM , a-Si TFT-LCD
Pixel Format	3840(RGB)×2160 (UHD) 238PPI	Configuration	RGB Vertical Stripe
Active Area	408.96 × 230.04 (H×V)	Outline Dim.	443.4 × 266.5 × 4.3 (H×V×D)
Bezel Area	-	Treatment	Antiglare
Luminance	260 cd/m² (Typ.)	Contrast Ratio	1000 : 1 (Typ.) (TM)
View Direction	Symmetry	Response Time	15 (Typ.)(Tr+Td) ms
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)	Operating Mode	ADS, Normally Black, Transmissive
Support Color	16.7M 100% Adobe RGB	Light Source	WLED , 15K hours , With LED Driver
Weight	-	Designed For	Laptop
Frequency	60Hz	Touch Panel	Without
Interface Type	eDP (4 Lanes) , eDP1.3 , 40 pins Connector
Power Supply	5.0V (Typ.)
Environment	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
