oem High quality 2.4 inch lcd screen display 240*320 TFT LCD display module with ILI9341 IC for handheld product

  • Part No.:ET024QV04-V
  • Size:2″ inch
  • Resolution:240x320
  • Panel Interface:
  • Display mode:TN
  • Outline Dimension:42.7(W)x59.40(H)x2.25(D)
  • Active Area:36.72(H)x48.96(V)
  • Viewing Angle L/R/U/D:80 80 80 80
  • Brightness（cd/m2）:200cd/m2
  • Operation / Storage Temp:-20~+60℃ / -30~+70℃
  • Touch:no
Get a quote

oem High quality 2.4 inch lcd screen display 240*320 TFT LCD display module with ILI9341 IC for handheld product

Display Mode TN
Part NO. ET024QV04-V
Size 2.4"
Resolution 240*320
Active Area(mm) 36.72(H) *48.96(V)
Brightness 200cd/m2
Operation Temperature -20~+60℃
Storage Temperature -30~+70℃
Viewing Angle 80 80 80 80
Interface MCU16bits interface 30PIN

oem High quality 2.4 inch lcd screen display 240*320 TFT LCD display module with ILI9341 IC for handheld product

oem High quality 2.4 inch lcd screen display 240*320 TFT LCD display module with ILI9341 IC for handheld product

oem High quality 2.4 inch lcd screen display 240*320 TFT LCD display module with ILI9341 IC for handheld product
