N156DCE-GN2 Innolux 15.6 Inch TFT LCD Display 3840×2160 eDP Interface High Brightness IPS LCD Module

N156DCE-GN2 Overview
N156DCE-GN2 is a 15.6 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, With LED Driver, without touch screen.N156DCE-GN2 supports display 3840(RGB)×2160 (UHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe,it's pixel density is 283 PPI. As for mechanical detail, it features active area of 344.218(W)×193.622(H) mm, outline size of 350.66(W)×217.32(H)×2.6(D) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 305/320g (Typ./Max.), shape stype of Slim (PCBA Flat, T≤3.2mm). As a AAS, Normally Black, Transmissive LCM product, N156DCE-GN2 can provides 600 cd/m² display brightness 1200:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 16/14 (Typ.)(Tr/Td) ms.

Feature
IPS
High Brightness 600 cd/m2
WLED Backlight
Matte

Application
For Outdoor high brightness.
