LQ156D1JW03 Sharp 15.6 Inch TFT LCD Display 3840×2160 eDP LCD Panel

LQ156D1JW03 Overview
LQ156D1JW03 supports display 3840(RGB)×2160 (UHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe, it's pixel density is 282 PPI. As for mechanical detail, it features active area of 345.6(W)×194.4(H) mm, outline size of 354.78(W)×217.1(H)×0.83(D) mm, with surface treament of Antiglare (Haze 42%), Hard coating (3H), net weight of 139g (Typ.), utilizing 0.30+0.30 mm mm plate. As a IPS, Normally Black, Transmissive CELL product, LQ156D1JW03 can provides 1000:1 transimissive contrast ratio, 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product have no backlight, With LED Driver. LQ156D1JW03 utilizes eDP (4 Lanes) as it's signal inputting systerm, which connected by 40 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.

Application
For Industrial.
