(17")

High Quality 17 inch Module 1280x960 Resolution LCD Panel IPS Display LVDS 30 Pins Interface High Contrast Screen

  • Part No.:DV170YGM-N10
  • Size:17″ inch
  • Resolution:1280x960
  • Panel Interface:LVDS (2 ch,8-bit)
  • Display mode:ADS,Transmissive
  • Outline Dimension:359x284.8mm(HxV)
  • Active Area:345.408x259.056mm(HxV)
  • Viewing Angle L/R/U/D:89/89/89/89
  • Brightness（cd/m2）:250cd/m²
  • Operation / Storage Temp:0~50°C / -20~60°C
  • Touch:no
Get a quote

Products Description

DV170YGM-N10-17inch-1280x960-TFT-LVDS-

LCD SPECIFICATION
Panel Size 17" Panel Type a-Si TFT-LCD, LCM
Pixel Number 1280×960 Configuration RGB Vertical Stripe
Active Area(mm) 345.408×259.056 mm (H×V) Outline(mm) 359×284.8 mm (H×V)
Bezel Area(mm) / Treatment Antiglare
Luminance 250 cd/m² Contrast Ratio 1000:1 (Typ.) (Transmissive)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Display Mode ADS, Normally Black, Transmissive
View Direction Symmetry Support Color 16.7M (6-bit + Hi-FRC)
Signal Interface LVDS (2 ch, 8-bit)
Input Voltage 5.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

DV170YGM-N10_01DV170YGM-N10_02DV170YGM-N10_03
