Feature |
Spec |
|
|
Display Spec. |
Size |
1.54 inch |
|
Resolution |
320*3(RGB)*320 |
|
|
Technology Type |
a-Si |
|
|
Pixel Configuration |
RGB Vertical Stripe |
|
|
Pixel pitch(mm) |
0.0867 (H)*0.0867(V) |
|
|
Display Mode |
Transmission mode, Normally Black |
|
|
Viewing Direction |
ALL |
|
|
Mechanical Characteristics |
LCM (W x H x D) (mm) |
35.5(H)*42.5(V)*2.665(T) |
|
Active Area(mm) |
27.744(H)*27.744(V) |
|
|
With /Without TSP |
With CTP |
|
|
TP Construction |
G+F |
|
|
LED Numbers |
3 LEDS |
|
|
LCD Driver IC |
ST7796S |
|
|
CTP Driver IC |
FT6236 |
|
|
Weight (g) |
TBD |
|
|
Electrical Characteristics |
Interface |
MIPI 1 lane |
|
|
Color Depth |
262K |
