COM32H3N74ULC Ortustech 3.2 Inch Transflective LCD Display 480x800 Sunlight Readable LCD Panel

  • Part No.:COM32H3N74ULC
  • Size:3.2″ inch
  • Resolution:480x800
  • Panel Interface:Parallel RGB (1 ch,8-bit)+SPI
  • Display mode:Transflective
  • Outline Dimension:46.66x78.55mm
  • Active Area:41.4x69mm
  • Viewing Angle L/R/U/D:80/80/80/80 (Min.)
  • Brightness(cd/m2):380cd/m²(Typ.)
  • Operation / Storage Temp:-20~70°C / -30~80°C
  • Touch:no

COM32H3N74ULC Overview
COM32H3N74ULC is a 3.2 inch diagonal a-Si TFT-LCD display screen product from Ortustech, with a built-in WLED backlight, without backlight driver, without touch screen.COM32H3N74ULC supports display 480(RGB)×800 (WVGA) with aspect ratio of 3:5 (W:H), whose pixels are arranged in RGB Vertical Stripe, according to calculation of Panelook it's pixel density is 294 PPI.It features active area of 41.4(W)×69(H) mm, outline size of 46.66(W)×78.55(H)×2.57(D) mm, with surface treament of Hard coating (3H), net weight of 14.0g (Typ.). As a Buenaview, Normally Black, Transflective LCM product, COM32H3N74ULC can provides 380 cd/m² display brightness 1000:1 transimissive contrast ratio, 3:1 (Typ.) reflective contrast ratio, 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 40/60 (Max.)(Tr/Tf) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors.

Application
For andheld & PDA,Industrial.
