3.0" lcd portait LCD module ET030QV01-K full viewing angle screen with 240x400 8/9/16/18Bit MCU 3/4SPI+16/18Bi

Part No.:ET030QV01-K
Size:3″ inch
Resolution:240x400
Panel Interface:
Display mode:IPS
Outline Dimension:45.04x77.00x2.6
Active Area:39.24(Ｈ)x65.40(Ｖ)
Viewing Angle L/R/U/D:80 80 80 80
Brightness（cd/m2）:450cd/m2
Operation / Storage Temp:-20～+70℃ / -30～+80℃
Touch:no

Model No.:	ET030QV01-K	Brightness:	450cd/m2
Brand:	Youritech	Interface:	8/9/16/18Bit MCU 3/4SPI+16/18Bit RGB 3-line/4-line
Panel Size:	3.0"	Viewing Angle:	80 80 80 80
Pixel:	240*400	Display Mode:	IPS
Active Area:	39.24(H)*65.40(V)	Storage Temperature:	-30~+80℃
Contrast Ratio:	500:1	Operation Temperature:	-20~+70℃

ET030QV01-K
