LCD above 17.3" (29")

29 Inch High Brightness Display 2000nits IPS 1920x624 LVDS Stretched Bar Display

Part No.:ET290BA01-Y
Size:29″ inch
Resolution:1920x624
Panel Interface:LVDS
Display mode:Transmissive
Outline Dimension:735x266mm
Active Area:698.4x229.17mm
Viewing Angle L/R/U/D:89/89/89/89
Brightness（cd/m2）:2000(Typ.)
Operation / Storage Temp:-20~70°C / -20~70°C
Touch:no

29 Inch High Brightness LCD Display Overview
The ET290BA01-Y is a 29-inch high-brightness IPS stretched bar display with a 1920×624 resolution and LVDS interface. It features a transmissive panel with an active area of 698.4×229.17 mm and overall dimensions of 735×266 mm. The display delivers 2000 cd/m² brightness, offers 89° viewing angles in all directions, operates and can be stored between –20–70 °C, and does not include touch functionality.

Outdoor High Brightness Displays Technology

YOURITECH. Comprehensive Manufacturing of Touchscreen, Driver Board Options

Youritech Driver Board
Youritech's R&D team provides experienced display panel motherboard solutions including industrial-grade and military-grade driver boards,manufacturing and designing industry-standard TTL/LVDS interface/CON driver boards, LCD driver boards/LCD inverters/EDP driver boards/4K driver boards,industrial displays solutions.

Production and Manufacturing
