ET260JJE-L07
|
Product size |
25.5-inch |
Type |
a-Si TFT-LCD, LCM |
|
Pixel Format |
1920(RGB)×1200 [WUXGA] 88PPI |
Configuration |
RGB Vertical Stripe |
|
Active Area |
550.08(H)×343.8(V) mm |
Outline Dim. |
582(H)×375.6(V) ×30.6(D) mm |
|
Bezel Area |
554.1(H)×347.8(V) mm |
Treatment |
Antiglare, Hard coating (3H) |
|
Luminance |
350 cd/m² (Typ.) |
Contrast Ratio |
1500:1 (Typ.) (TM) |
|
View Direction |
Symmetry |
Response Time |
15/5 (Typ.)(Tr/Td) |
|
Viewing Angle |
88/88/88/88 (Typ.)(CR≥10) |
Operating Mode |
Super MVA, Normally Black, Transmissive |
|
Support Color |
16.7M 72% NTSC |
Light Source |
WLED , 50K hours , With LED Driver |
|
Weight |
3.65/3.85Kgs (Typ./Max.) |
Designed For |
Industrial |
|
Frequency |
60Hz |
Touch Panel |
Without |
|
Interface Type |
LVDS (2 ch, 8-bit) , 30 pins Connector |
||
|
Power Supply |
5.0V (Typ.) |
||
|
Environment |
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
||
