LCD above 17.3" (19")

19 Inch High Brightness Display 1200nits IPS 1440x900 LVDS TFT LCD Display

Part No.:ET190BA01-H
Size:19″ inch
Resolution:1440x900
Panel Interface:LVDS
Display mode:Transmissive
Outline Dimension:428x278mm
Active Area:408.24x255.15mm
Viewing Angle L/R/U/D:85/85/80/80
Brightness（cd/m2）:1200(Typ.)
Operation / Storage Temp:-10~50°C / -20~60°C
Touch:no

19 Inch High Brightness LCD Display Overview
19 Inch High Brightness Display 1200nits IPS 1440x900 LVDS TFT LCD Display.

More 19 Inch High Brightness Display For Reference
ET190BA01-T (1920x320, LVDS, 1500nits, 0~50°C, 500x119.6mm)
ET190SX01-HT (1280x1024, LVDS, 2000nits, -30~85°C, 396x324mm)
ET190BA01-Y (1920x290, LVDS, 700nits, 0~50°C, 482x73mm)
ET190BA01-H (1440x900, LVDS, 1200nits, -10~50°C, 428x278mm)

Outdoor High Brightness Displays Technology

YOURITECH. Comprehensive Manufacturing of Touchscreen, Driver Board Options

Youritech Driver Board
Youritech's R&D team provides experienced display panel motherboard solutions including industrial-grade and military-grade driver boards,manufacturing and designing industry-standard TTL/LVDS interface/CON driver boards, LCD driver boards/LCD inverters/EDP driver boards/4K driver boards,industrial displays solutions.

Production and Manufacturing
