10.2"-17.3" LCD Display (12.3")

12.3 Inch High Brightness Display 1200nits 1920x720 LVDS Wide Temperature TFT LCD Display

Part No.:ET123BA20-T
Size:12.3″ inch
Resolution:1920x720
Panel Interface:LVDS
Display mode:Transmissive
Outline Dimension:310x128mm
Active Area:292.03x109.51mm
Viewing Angle L/R/U/D:88/88/88/88
Brightness（cd/m2）:1200(Typ.)
Operation / Storage Temp:-30~80°C / -30~85°C
Touch:no

12.3 Inch High Brightness LCD Display Overview
ET123BA20-T is a 12.3-inch high-brightness TFT LCD display featuring a 1920 × 720 resolution in transmissive mode. It utilizes an LVDS interface and provides a typical brightness of 1200 cd/m² with wide viewing angles of 88° left/right/up/down. The display has an active area of 292.03 × 109.51 mm and an outline size of 310 × 128 mm, supporting operation from −30 to 80 °C and storage from −30 to 85 °C. Touch functionality is not included.

Outdoor High Brightness Displays Technology

YOURITECH. Comprehensive Manufacturing of Touchscreen, Driver Board Options

Youritech Driver Board
Youritech's R&D team provides experienced display panel motherboard solutions including industrial-grade and military-grade driver boards,manufacturing and designing industry-standard TTL/LVDS interface/CON driver boards, LCD driver boards/LCD inverters/EDP driver boards/4K driver boards,industrial displays solutions.
