RV156QUM-N00 BOE 15.6 Inch TFT LCD Display 3840×2160 Sunlight Readable eDP Interface LCD Module

  • Part No.:RV156QUM-N00
  • Size:15.6″ inch
  • Resolution:3840x2160
  • Panel Interface:eDP (4 Lanes)
  • Display mode:ADS,Transmissive
  • Outline Dimension:376.6x240mm
  • Active Area:345.6x194.4mm
  • Viewing Angle L/R/U/D:85/85/85/85 (Typ.)
  • Brightness(cd/m2):850cd/m²(Typ.)
  • Operation / Storage Temp:0~50°C / -20~60°C
  • Touch:no

RV156QUM-N00 Overview
RV156QUM-N00 is a 15.6 inch diagonal a-Si TFT-LCD display screen product from BOE, with a built-in WLED backlight, without backlight driver, without touch screen.RV156QUM-N00 supports display 3840(RGB)×2160 (UHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe, according to calculation of Panelook it's pixel density is 282 PPI. As for mechanical detail, it features active area of 345.6(W)×194.4(H) mm, outline size of 376.6(W)×240(H)×11.2(D) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of TBD. As a ADS, Normally Black, Transmissive LCM product, RV156QUM-N00 can provides 850 cd/m² display brightness 1000:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 35 (Max.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors.

Feature
IPS
High Brightness 850 cd/m2
WLED Backlight
Matte

Application
For Outdoor high brightness,Industrial.
