| Product size | 4.0-inch | Type | LCM, LTPS TFT-LCD |
| Pixel Format | 480(RGB)×854 (FWVGA) 243PPI | Configuration | RGB Vertical Stripe |
| Active Area | 50.04 × 89.03 (H×V) | Outline Dim. | 53.94 × 98.19 (H×V×D) |
| Bezel Area | 51.24 × 91.03 (H×V) | Treatment | Antiglare |
| Luminance | 350 cd/m² (Typ.) | Contrast Ratio | 800 : 1 (Typ.) (TM) 2:1 (Typ.) (RF) |
| View Direction | Symmetry | Response Time | 45/45 (Max.)(Tr/Td) ms |
| Viewing Angle | 70/70/70/70 (Min.)(CR≥10) | Operating Mode | VMW, Normally Black, Transflective |
| Support Color | 16.7M 80% NTSC | Light Source | 1S6P WLED , No Driver |
| Weight | TBD | Designed For | Mobile Phone |
| Frequency | 60Hz | Touch Panel | Without |
| Interface Type | MDDI (2 data lanes) , 24 pins FPC | ||
| Power Supply | 1.8/2.8V (Typ.)(VDD/VDDI) | ||
| Environment | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C | ||
