7.1"-10.1" LCD Display (8")

New 8 inch Lcd Panel 1024x768 Resolution IPS Display LVDS 40 Pins Interface TFT LCD Module High Brightness Screen

Part No.:ET080WX02-T
Size:8″ inch
Resolution:1024x768
Panel Interface:LVDS 40 Pins
Display mode:IPS,Transmissive
Outline Dimension:162.05x121.54
Active Area:/
Viewing Angle L/R/U/D:IPS
Brightness（cd/m2）:350nits
Operation / Storage Temp:-20~70°C / -30~80°C
Touch:no

Products Description

ET080WX02-T-8.0inch-TTF-1024x768-LVDS-1 ET080WX02-T_01

Panel Size	8"
Pixel Number	1024x768
Operating Mode	IPS, Transmissive
Display area	162.05x121.54
Brightness	350nits
Viewing Angle	IPS
Signal Interface	LVDS 40 Pins
Display Color	262k/16.7M
Contrast Ratio	500:1
Environment	Operating Temp.: -20~ 70 °C ; Storage Temp.: -30 ~ 80 °C

ET080WX02-T_02 ET080WX02-T_03
