G070VTN02.0 AUO 7 Inch TFT LCD Display 800x480 Sunlight Readable Wide Temperature LCD Panel

  • Part No.:G070VTN02.0
  • Size:7″ inch
  • Resolution:800x480
  • Panel Interface:Parallel RGB (1 ch,6-bit)
  • Display mode:TN,Normally White
  • Outline Dimension:169(Hx103.51(V)
  • Active Area:152.4(H)x91.44(V)
  • Viewing Angle L/R/U/D:65/65/50/60
  • Brightness(cd/m2):1500(Typ.)
  • Operation / Storage Temp:-30~70°C / -40~95°C
  • Touch:no

G070VTN02.0 Overview
G070VTN02.0 supports display 800(RGB)×480 (WVGA) with aspect ratio of 15:9 (W:H), whose pixels are arranged in RGB Vertical Stripe.It features active area of 152.4(W)×91.44(H) mm, outline size of 169(W)×103.51(H)×6.52(D) mm, viewing area size of 155.41(W)×94.66(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 157g (Typ.). As a TN, Normally White, Transmissive LCM product, G070VTN02.0 can provides 1500 cd/m² display brightness 600:1 transimissive contrast ratio, 65/65/50/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle , and response time of 12/18 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors, also with performance of color gamut 66% (NTSC)..

Feature
Wide Temperature
3G Vibration
Ultra High Brightness 1500nits
U/D,L/R Reverse
Matte

Application
For Handheld & PDA,Industrial,Outdoor high brightness.
