| LCD SPECIFICATION | ||||
| Panel Size | 17.3" | Panel Type | a-Si TFT-LCD , LCM | |
| Pixel Number | 2560(RGB)×1440 (Quad-HD) 170PPI | Configuration | RGB Vertical Stripe | |
| Active Area(mm) | 381.85 × 214.79 (H×V) | Outline(mm) | 389.89 × 238.01 × 3.5 (H×V×D) | |
| Bezel Area(mm) | - | Treatment | Antiglare, Hard coating (3H) | |
| Luminance | 300 cd/m² (Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (TM) | |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | ADS, Normally Black, Transmissive | |
| View Direction | Symmetry | Response Time | 9 (Typ.)(Tr+Td); 3 (Typ.)(G to G)(OD) ms | |
| Support Color | 16.7M 100% sRGB | Backlight | 10S6P WLED , 15K hours , With LED Driver | |
| Outline Shape | Flat (PCBA Flat, T3.4~4.0mm) | Used for | Laptop, Gaming | |
| Frame Rate | 165Hz | Touchscreen | Without | |
| Signal Interface | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector | |||
| Input Voltage | 3.3V (Typ.) | |||
| Environment | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C | |||
