5.1"-7" LCD Display (7")

Factory OEM 7 inch LCD Panel 720x1280 High Resolution LCD Display With 25 Pins MIPI Interface TFT LCD Module

Part No.:ET070HD01-V
Size:7″ inch
Resolution:720x1280
Panel Interface:MIPI 2 Lanes
Display mode:TFT,Transmissive
Outline Dimension:90.34(H)x126.95(V)x2.4(D)Mm
Active Area:86.94(H)x154.56(V)Mm
Viewing Angle L/R/U/D:ALL O’clock
Brightness（cd/m2）:320nit
Operation / Storage Temp:/ / /
Touch:no

Products Description
