COM37H3M05DTC Ortustech 3.7 Inch Transflective Display 480×640 Parallel RGB TFT LCD Display With 4-wire Resistive Touch

COM37H3M05DTC Ortustech 3.7 Inch Transflective Display 480×640 Parallel RGB TFT LCD Display With 4-wire Resistive Touch Overview

COM37H3M05DTC is a 3.7 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, touchscreen 4-wire Resistive Touch.COM37H3M05DTC supports display 480(RGB)×640 (VGA) with aspect ratio of 3:4 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 56.16(W)×74.88(H) mm, outline size of 65(W)×89(H)×5.9(D) mm, with surface treament of Hard coating (3H), net weight of 44.1g (Typ.). As a TN, Normally White, Transflective LCM product, COM37H3M05DTC can provides 230 cd/m² display brightness 300:1 transimissive contrast ratio, 2:1 (Typ.) reflective contrast ratio, 35/35/15/50 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 40/60 (Max.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted 6S1P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, external backlight driver is additionally needed. COM37H3M05DTC utilizes Parallel RGB (1 ch, 6-bit) as it's signal inputting systerm, which connected by 39 pins FPC with power supply voltage of 3.0V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.

Ortustech Transflective Display Advantage

-Sunlight Readable Low PowerConsumption
-Supply Long-term Stable
-High-Mix/Low-Volume Production
-Customer-oriented Support System
-Customized Product Support

Ortustech Transflective Display Application

Ortustech Transflective Display Production and Manufacturing
