COM35T3137KTX Ortustech 3.5 Inch TFT LCD Display 320x240 Parallel RGB LCD Panel For Handheld PDA

Part No.:COM35T3137KTX
Size:3.5″ inch
Resolution:320x240
Panel Interface:Parallel RGB (1 ch,8-bit) + SPI
Display mode:TN,Normally White,Transmissive
Outline Dimension:76.9x63.9mm
Active Area:70.32x52.74mm
Viewing Angle L/R/U/D:65/65/40/65 (Typ.)
Brightness（cd/m2）:320cd/m²(Typ.)
Operation / Storage Temp:-10~70°C / -20~80°C
Touch:no

COM35T3137KTX Overview
COM35T3137KTX supports display 320(RGB)×240 (QVGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 70.32(W)×52.74(H) mm, outline size of 76.9(W)×63.9(H)×4.73(D) mm, net weight of 41.0g. As a TN, Normally White, Transmissive LCM product, COM35T3137KTX can provides 320 cd/m² display brightness 60:1 transimissive contrast ratio, 65/65/40/65 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 40/60 (Max.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors.

Application
For andheld & PDA,Industrial.
