0.48"-5" LCD Display (2.7")

COM27H2P62XTC Ortustech 2.7 Inch TFT LCD Display 240x320 Transflective LCD Panel With 4-wire Resistive Touch

  • Part No.:COM27H2P62XTC
  • Size:2.7″ inch
  • Resolution:240x320
  • Panel Interface:/
  • Display mode:Transflective
  • Outline Dimension:/
  • Active Area:41.04(W)x54.72(H)mm
  • Viewing Angle L/R/U/D:80/80/80/80 (Min.)
  • Brightness(cd/m2):/
  • Operation / Storage Temp:-20~70°C / -30~80°C
  • Touch:yes

Overview
COM27H2P62XTC is a 2.7 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, touchscreen 4-wire Resistive Touch. COM27H2P62XTC supports display 240(RGB)×320 (QVGA) with aspect ratio of 3:4 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 41.04(W)×54.72(H) mm. As a VA, Normally Black, Transflective LCM product, COM27H2P62XTC can provides , 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry . Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors.

Application
For andheld & PDA,Industrial.
