COM27H2M95XLC 2.7 Inch TFT LCD Display 240x320 Transflective LCD Panel For Handheld & PDA

  • Part No.:COM27H2M95XLC
  • Size:2.7″ inch
  • Resolution:240x320
  • Panel Interface:CPU
  • Display mode:Transflective
  • Outline Dimension:47(W)x66(H)mm
  • Active Area:41.04(W)x54.72(H)mm
  • Viewing Angle L/R/U/D:80/80/80/80 (Min.)
  • Brightness(cd/m2):400cd/m²(Typ.)
  • Operation / Storage Temp:-20~70°C / -30~80°C
  • Touch:no

Overview
COM27H2M95XLC supports display 240(RGB)×320 (QVGA) with aspect ratio of 3:4 (W:H), whose pixels are arranged in RGB Vertical Stripe.It features active area of 41.04(W)×54.72(H) mm, outline size of 47(W)×66(H)×4.34(D) mm, with surface treament of Hard coating (3H), net weight of 19.0g (Typ.). As a TN, Normally White, Transflective LCM product, COM27H2M95XLC can provides 400 cd/m² display brightness 400:1 transimissive contrast ratio, 8.5:1 (Typ.) reflective contrast ratio, 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) viewing angle , and response time of 40/60 (Max.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors.

Application
For andheld & PDA,Industrial.
