COM20T2811G Ortustech 2 Inch 354x240 LCD Display For Digital Still Camera

Part No.:COM20T2811G
Size:2″ inch
Resolution:354x240
Panel Interface:Serial RGB (6-bit) + SPI
Display mode:Transmissive
Outline Dimension:47x40.2mm
Active Area:39.88x30mm
Viewing Angle L/R/U/D:/
Brightness（cd/m2）:250cd/m²(Typ.)
Operation / Storage Temp:-10~60°C / /
Touch:no

Overview
COM20T2811G supports display 354×240 with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Delta. It features active area of 39.88(W)×30(H) mm, net weight of TBD. As a TN, Normally White, Transmissive LCM product, COM20T2811G can provides 250 cd/m² display brightness, best view direction on 6 o'clock . Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors.

Application
For andheld & PDA,Industrial.
