AMS395GB01 Samsung 4 Inch OLED Display 360x640 High Brightness MIPI Interface Amoled Panel

Part No.:AMS395GB01
Size:4″ inch
Resolution:360x640
Panel Interface:MIPI (1 data lane)
Display mode:/
Outline Dimension:53.76x97.16mm
Active Area:49.14x87.36mm
Viewing Angle L/R/U/D:/
Brightness（cd/m2）:640cd/m²(Typ.)
Operation / Storage Temp:-15~70°C / -40~85°C
Touch:no

AMS395GB01 Overview
AMS395GB01 supports display 360(RGB)×640 (nHD) with aspect ratio of 9:16 (W:H), whose pixels are arranged in RGB Vertical Stripe.It features active area of 49.14(W)×87.36(H) mm, outline size of 53.76(W)×97.16(H) mm, net weight of 23.6g (Typ.). AMS395GB01 can provides 640 cd/m² display brightness 1300:1 transimissive contrast ratio . Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 105% (NTSC). This product emiting itself . AMS395GB01 utilizes MIPI (1 data lane) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.7/1.8V (Typ.)(VPNL/VDDI).

Feature
Wide Color Gamut
DCI-P3
Adobe RGBs
Hight Brightness

Application
For Handheld & PDA,Industrial,Outdoor high brightness.
