AM014RN90004V0 Original 1.39 Inch Round OLED Display 454x454 MIPI Circular Amoled For Wearable

AM014RN90004V0 Overview
AM014RN90004V0 is a 1.39 inch diagonal AM-OLED display screen product from TRULY, it self emiting, without touch screen.AM014RN90004V0 supports display 454(RGB)×454 with aspect ratio of 1:1 (W:H), whose pixels are arranged in RGB Vertical Stripe,it's pixel density is 325 PPI. As for mechanical detail, it features active area of 35.412(W)×35.412(H) mm, outline size of 38.212(W)×39.712(H)×0.62(D) mm, with surface treament of Hard coating. AM014RN90004V0 can provides 350 cd/m² display brightness 1000:1 transimissive contrast ratio, 80/80/80/80 (Min.) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 0.5 (Max.)(Tr+Tf) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 100% (NTSC).

Screen Size:1.39 inch
Resolution:454x454
Brand: Truly
1.39 Inch 454x454 Round OLED Display.
Refresh Rate:60Hz

Application
For Wearable.
