5 Inch Transflective LCD Display Overview
The ET050TR01-TV is a 5-inch transflective LCD display designed for handheld PDAs. It features a 480×800 resolution with a CPU interface. The display has an active area of 64.8×108 mm within an outline size of 70.8×118.75 mm. It provides a typical brightness of 160 cd/m² and viewing angles of 25°/25°/35°/35° (L/R/U/D). The operating temperature range is –20 °C to 70 °C, with storage from –40 °C to 85 °C. This model does not include touch functionality.
More 5 Inch Transflective LCD Display For Reference
ET050TR01-TV (480x800, CPU, 160nits, -20~70°C, 70.8x118.75mm)
COM50H5N15ULC (800x480, LVDS, 1200nits, -30~85°C, 124x80.82mm)
ET050TR01-K (800x480, TTL, 280nits, -20~70°C, 120.7x75.9mm)
COM50H5N25ULC (800x480, LVDS, 1200nits, -30~85°C, 124x80.82mm)
COM50H5N23UTC (800x480, LVDS, 500nits, CTP(Air))
COM50H5N17ULC (720x1280, MIPI, 400nits, -20~70°C, 67.84x120.22mm)
LS050K7SX01 (720x1280, MIPI, 400nits, -20~70°C, 67.2x120.77mm)
Production and Manufacturing
At Youritech, we design and manufacture standard, semi-custom and full custom LCD/OLED display modules,touch screen,driver board,open frame. Contact us today,let our engineering team quickly and accurately feedback you with details.
