19.1 inch lcd display with 1920x360 LVDS 300nits brightness for digital signage

Product size

19.1 inch   (1/3 cut of 21.5")

Type

a-Si TFT-LCD , LCM

Pixel Format

1920(RGB)×360  102PPI

Configuration

RGB Vertical Stripe

Active Area

476.64(H)×89.37(V) mm

Outline Dim.

491.5(H)×109.4(V) ×12.8(D) mm

Bezel Area

-

Treatment

Antiglare (Haze 25%)

Luminance

300 cd/m² (Typ.)

Contrast Ratio

1200:1 (Typ.) (TM)

View Direction

Symmetry

Response Time

30 (Typ.)(Tr+Td)

Viewing Angle

89/89/89/89 (Typ.)(CR≥10)

Operating Mode

ADS, Normally Black, Transmissive

Support Color

16.7M   72% NTSC

Light Source

WLED , 30K hours , W/O Driver

Weight

780g (Typ.)

Designed For

Digital Signage Stretched Bar LCD

Frequency

60Hz

Touch Panel

Without

Interface Type

LVDS (2 ch, 8-bit) , 30 pins Connector

Power Supply

5.0V (Typ.)

Environment

Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
